CPVC Pipe for Hot and Cold Water

1. Dia: Dia: DN20-630mm(1/2 inch-24 inch).
2. Pressure Class: PN5 - PN25.
3. Delivery: 5-10 days depending on the total quantity.
4. Packing: 3/6/9/12m/pcs for straight, with plain ends, RRJ end or SCJ end.
5. Product inspection: Raw material inspection. Finished product inspection. Third party inspection upon clients request.

Send E-mail Inquiry Now
Introduction Specifications Products Technical

Chlorinated Polyvinyl Chloride(C-PVC) pipe system for hot and cold water

Products details information Company/factory strength
Product name CPVC pipe for hot and cold water Production capacity 160*40ft containers/month
Brand Def pipeline(or OEM) Sample Free sample available
Dia. ranges DN20-630mm(1/2 inch-24 inch) Delivery time 5-10 days, depending on the quantity
Pressure class PN5 - PN25 Certificates ISO9001, OHSAS 18001, ISO14001, ISO45001, CE...
Raw material C PVC Management Effective 8S management system
Standards ISO4422, ISO 1452, ISO 15493, ASTM D1785, EN 1401, EN 1452, EN 15493, EN 1767, BS 3505 Test/inspection National standard laboratory, Pre-delivery inspection
Color Grey, Blue, Others colors is option Warranty 50 years with normal use
Packing RRJ end or SCJ end, 3/6/9/12m/pcs for straight, with plain ends No. of employees More than 300
Application Drinking water, Fresh water, Drainage, Oil and Gas, Mining, Dredging, Marine, Irrigation, Industry, Chemical, Fire fighting... Quality QA & QC system, Ensure traceability of each process
Matching products PVC fitting, PVC solvent cement fitting, PVC rubber ring joints, PVC threaded fittings, Flanges, Glue and tools, etc. Service Research, Design, Sales, Solution providing, Test, Manufacture, Aftersales service

Customers are welcome to visit the factory or conduct a third-party audit.

Welcome to contact us for products details and professional service.

Please send email to:   jolin@defpipe.com.   Or   (WhatsApp):  +86 13298353566.

Description of Chlorinated Polyvinyl Chloride(C-PVC) pipe system for hot and cold water

PVC (polyvinyl chloride) chlorinated by free radical chlorination. CPVC is produced by adding chlorine to PVC during a slurry or fluid bed chlorination process. The chlorination reaction is initiated by UV light. Chlorinated PVC is mixed with the ingredients needed for further processing for the desired properties. Chlorine added to PVC gives CPVC higher temperature performance and improves fire and corrosion resistance. Pipes and fittings made from C-PVC can withstand a wider range of temperatures. This makes C-PVC a popular choice for plumbing systems in residential and commercial buildings.

CPVC pipe is available in nominal sizes ranging from 1/2 to 2 inches copper pipe size (CTS) and pipe sizes ranging from 1/2 to 24 inches (Sch 40/80) iron pipe size (IPS). CPVC pipe is SDR11 (1/2 to 2 inches) with standard hydrostatic pressure ratings of 400 psi at 73ºF (2,750 kPa at 23ºC) and 100 psi at 180ºF (690 kPa at 82ºC).

Def pipeline is the ideal piping solution with the safty and reasonable price.

PVC Fittings

  • PVC Rubber Ring Joint

  • PVC Threaded Fitting

  • PVC Solvent-cement Fitting

Advantages of Chlorinated Polyvinyl Chloride(C-PVC) pipe system for hot and cold water

  • 1. CPVC pipes and fittings can guarantee the safety and long-term reliability of drinking water.
  • 2. CPVC pipes and fittings are anti-nodule , anti-corrosion and anti-deposition.
  • 3. CPVC pipes and fittings are resistant to chlorine and chloramines.
  • 4. CPVC pipes and fittings are light in weight and easy to transport.
  • 5. CPVC pipes and fittings are available in various sizes.
  • 6. CPVC pipes and fittings are anti-noise and anti-water hammer.
  • 7. CPVC pipes and fittings have no waste value and avoid theft.
  • 8. CPVC pipes and fittings are durable and stand up to field installations.
  • 9. CPVC pipes and fittings is universal compatibility.

Welcome to contact us for products details and professional service.

Please send email to:   jolin@defpipe.com.   Or   (WhatsApp):  +86 13298353566.

Specification of Chlorinated Polyvinyl Chloride(C-PVC) pipe system for hot and cold water

Nom. Pipe Size (in.) O.D.(in.) Schedule 40 Dimensions(in) Schedule 80 Dimensions(in)
Average I.D. Min. Wall Nom. Wt./Ft. Max. W.P Average I.D. Min. Wall Nom. Wt./Ft. Max. W.P
 1/4 0.54 0.344 0.088 0.096 780 0.282 0.119 0.117 1130
 3/8 0.675 0.473 0.091 0.128 620 0.403 0.126 0.162 920
 1/2 0.84 0.602 0.109 0.19 600 0.526 0.147 0.238 850
 3/4 1.05 0.804 0.113 0.253 480 0.722 0.154 0.322 690
1 1.315 1.029 0.133 0.371 450 0.936 0.179 0.473 630
1 1/4 1.66 1.36 0.14 0.502 370 1.255 0.191 0.654 520
1 1/2 1.9 1.59 0.145 0.599 330 1.476 0.2 0.793 470
2 2.375 2.047 0.154 0.803 280 1.913 0.218 1.097 400
2 1/2 2.875 2.445 0.203 1.267 300 2.29 0.276 1.674 420
3 3.5 3.042 0.216 1.66 260 2.864 0.3 2.242 370
3 1/2 4 3.521 0.226 1.996 240 3.326 0.318 2.735 350
4 4.5 3.998 0.237 2.363 220 3.786 0.337 3.277 320
5 5.563 5.016 0.258 2.874 190 4.768 0.375 4.078 280
6 6.625 6.031 0.28 4.164 180 5.709 0.432 6.258 280
8 8.625 7.942 0.322 6.268 160 7.565 0.5 9.506 250
10 10.75 9.976 0.365 8.886 140 9.493 0.593 14.095 230
12 12.75 11.889 0.406 11.751 130 11.294 0.687 19.392 230
14 14 13.073 0.437 13.916 130 12.41 0.75 23.261 220
16 16 14.94 0.5 18.167 130 14.213 0.843 29.891 220
18 18 16.809 0.562 22.965 130 16.014 0.937 37.419 220
20 20 18.743 0.593 29.976 120 17.814 1.031 45.789 220
24 24 22.544 0.687 37.539 120 21.418 1.218 64.959 210

Welcome to contact us for products details and professional service.

Please send email to:   jolin@defpipe.com.   Or   (WhatsApp):  +86 13298353566.

Def Pipeline invests a lot of money in product research and development and technological innovation every year to implement modern manufacturing processes, improve production efficiency and service quality to ensure that DEF is always in the leading position in the industry. Def Pipeline pays attention to the innovation of products and the durability of service life in the design and development. We pay attention to the safety of the production process and the precision of processing in the production process. And pays attention to excellence and high-end product quality in the inspection process. Def Pipeline focuses on the future needs of the market. With our rich product portfolio of PVC pipe & fittings and professional technical knowledge, Def Pipeline provides product technical and price support at every customer project stage. Def Pipeline helps customers make the plan to reduce the procurement cost and installation costs reasonably.

  • PVC Solvent-cement Fitting

  • PVC Rubber Ring Joint

  • PVC Threaded Fitting

  • PVC Pipe and Fitting

  • UPVC Pipe for Water Supply

  • UPVC Pipe for Industry

  • UPVC Pipe for Irrigation System

  • UPVC Pipes ASTM SCH40 SCH80 and SCH120

  • UPVC Underground Drainage and Sewerage Pipe

  • UPVC Conduit for Underground Telecommunication Cable

  • CPVC Pipes ASTM SCH40 and SCH80

  • CPVC Cable Conduit

  • Modified Polyvinyl Chloride (PVC-M) Pipe

  • Perforated(Slotted) U PVC/PVC M Pipe

  • Oriented Polyvinyl Chloride(PVC-O) Pipe

Please send email to:   jolin@defpipe.com.   Or   (WhatsApp):  +86 13298353566.

CPVC Pipe for Hot and Cold Water



The following are the specifications of CPVC Pipe for Hot and Cold Water of different standards. Technical parameters, pictures and technical brochure as below for online preview and download.
